技术参数Specifications | CA6161 CA6161B CA6161C | CA6261 CA6261B CA6261C | ||||
床身最大工件直径Max. Swing over bed | 610mm | |||||
刀架上最大工件直径Max. Swing over carriage | 370mm | |||||
马鞍槽最大工件直径Max. swing in gap | -- | 830mm | ||||
马鞍槽有效长度Effective gap length | -- | 210mm | ||||
最大工件长度Max. length of work piece | 750mm/1000mm/1500mm/2000mm/3000mm/4000 | |||||
床身宽度Width of bed | 400mm | |||||
刀杆截面Section of turning tool | 25x25mm | |||||
主轴 Spindle | 主轴转速范围Spindle speeds | 10-1400rpm/16-1400rpm（24steps） | ||||
| 主轴内孔Hole through spindle | 52mm.（80mm）. [105mm] | ||||
| 主轴孔锥度Spindle taper | 莫式NO.6（MT6）（Φ90 1：20）[Φ113 1：20] | ||||
进给 Feed | 进给数量Number of feeds | 64种（kinds）（for each） | ||||
| 公制螺纹Range of metric threads（kinds） | （1-192mm）44种（44kinds） | ||||
| 英制螺纹Range of inch threads（kinds） | （2-24tpi）21种（21kinds） | ||||
| 模数螺纹Range of module threads（kinds） | 0.25-48(模数39种)(Moduie39kinds) | ||||
| 径节螺纹Range of pitch threads（kinds） | 1-96DP(37种)（37kinds） | ||||
尾座 Tailstock | 尾座主轴最大行程Max. tail stock spindle travel | 150mm | ||||
| 尾座主轴直径Tail stock spindle diameter | 75mm | ||||
| 尾座主轴孔锥度Taper of tail stock spindle center hole | 莫氏NO.5(MT5) | ||||
主电机Main motor | 7.5KW(10HP) | |||||
包装尺寸 Packing dimensions (L*W*Hmm) | Overall dimensions for750mm | 2550x1140x1750 | ||||
| Overall dimensions for1000mm | 2700x1140x1750 | ||||
| Overall dimensions for1500mm | 3200x1140x1750 | ||||
| Overall dimensions for2000mm | 3700x1140x1750 | ||||
| Overall dimensions for2200mm | 4030x1140x1750 | ||||
| Overall dimensions for3000mm | 4850x1140x1750 | ||||
| Overall dimensions for4000mm | 5800x1140x1750 | ||||
重量 Weight (kg) | Length | 毛重 净重
| ||||
| Weight for 750mm | 2300 2180 | ||||
| Weight for 1000mm | 2380 2250 | ||||
| Weight for 1500mm | 2577 2437 | ||||
| Weight for 2000mm | 2940 2787 | ||||
| Weight for 2200mm | 3120 2970 | ||||
| Weight for 3000mm | 3600 3450 | ||||
| Weight for 4000mm | 3950 3800 | ||||
