技术参数

Specifications

Units

CAK6180 CAK6180B CAK6180C

床身上最大回转直径

Max.swing over bed

mm

800

最大加工长度

Max.processing length

mm

750/1000/1500/2000/3000

主轴锥度

Spindle taper

MT6(Ø90 1:20 for B)[Ø113 1:20 for C]

卡盘尺寸

Chuck size

mm

C6(D8)[D8]

主轴通孔直径

Spindle bore

mm

52(80 for B)[105 for C]

主轴转速

3档

（自动变速）

Spindle speed 3 steps (auto change gear)

rpm

Independent spindle:100-1600

21-1500(I:21-150,II:66-500,III:162-1500)

尾座套筒行程

Tailstock sleeve travel

mm

150

尾座套筒锥度

Tailstock sleeve taper

MT5

定位精度

Position accuracy

mm

±0.015

重复定位精度

Repositioning accuracy

mm

±0.006

X/Z快移速度

X/Z axis rapid traverse

m/min

4/6

主轴功率

Spindle motor

kw

7.5

11

包装尺寸

Machine dimension for 750

mm

2550x1550x1900

Machine dimension for 1000

mm

2750x1550x1900

Machine dimension for 1500

mm

3250x1550x1900

Machine dimension for 2000

mm

3700x1550x1900

Machine dimension for 3000

mm

4710x1550x1900

重量

Machine weight for 750

kg

2400/3000

Machine weight for 1000

kg

2550/3150

Machine weight for 1500

kg

2750/3350

Machine weight for 2000

kg

2980/3550

Machine weight for 3000

kg

3800/4400
